Measuring Pipe Size DN15
Basic Info.
Model NO. | CX-WUFM-TDS-100F1-B1 |
Main Application | Water, Wastewater, Diesel Fuel, Fuel Oil, Nature Gas, Corrosive Liquid/Gas |
Size | DN100-500 |
Sensor | Clamp-on/External |
Application | Industrial Production |
Type | Ultrasonic Flow Meter |
Measuring Media | Liquid |
Measuring Principle | Electrical Principles |
Measurement Object | Open Channel |
Certification | JIS, DIN, ANS, GB, CE, RoHS, ISO |
Communication | RS232interface |
Protection Grade | IP65 |
Applicable Caliber | DN5-DN6000 |
Product Name | Ultrasonic Flow Meter |
Transport Package | Carton |
Specification | CE SGS |
Trademark | GN |
Origin | Shanghai |
HS Code | 90261000 |
Production Capacity | 1000PCS/Month |
Packaging & Delivery
Package Size 60.00cm * 40.00cm * 30.00cm Package Gross Weight 8.000kgProduct Description
Product DescriptionUltrasonic flow meter uses the time difference principle of ultrasonic wave propagation in the medium to measure the flow rate.It is mainly used to measure liquid, such as ultra-pure liquid, chemical, raw sewage, reclaimed water, cooling water, river water, plant sewage, etc.
Product Name | wall-mounted Ultrasonic Flowmeter |
Accuracy | ±1%R, flow velocity large than 0.2m/s |
Diameter | DN32 - DN6000 mm |
Medium | Pure liquids such as tap water, alcohol, sea water, etc |
Power Supply | Isolated DC8-36V or AC85-264V |
Power Consumption | Working current 50 mA |
Communication | RS485, Support MODBUS protocol |
Power Consumption | 6W |
Units | meters, feet, cubic meters, liters, cubic feet, US gallons, SupportCustomization |
Pipe Material | carbon steel, stainless steel, cast iron, copper, PVC, aluminum, glass steel and other homogeneous medium pipes |
Totalizer | 7-digit totals for net, positive and negative flow respectively |
Optional Output | 1 isolated RS485 output; 1 isolated 4-20mA or 0-20mA output (activeand passive optional);Dual-channel isolated OTC output (programmable between OTC1pulse width 6-1000ms, default 200ms) |
Q1.Are you a factory? A1:We are based in Shanghai, China, start from 2011.Main production and sales of various industrial flow meters and other products.Welcome to visit! Q2.what can you buy from us? A2:We can provide one-stop flow meter services, providing sales of instruments such as flow meters, liquid level gauges, vacuum gauges, pumps, sensors, industrial thermometers, etc. Q3. What is your terms of packing? A3: Generally, JSN brand colorful cardboard boxes packing.OEM brandbrown cardboard boxes packing. Q4. How about your delivery time? A4: Generally, standard type : 6-7 working days after confirm the order.non-standard type: 8-10 working days after confirm the order. Q5. What's your MOQ? A5: We have no MOQ demand, 1 piece for test purpose at first is acceptable. Q6. How do you ensure good product quality? A6: We have a complete quality control system; All of our products are fully checked by IQC, OQC departments before ship to our clients. Q7. How long your quotation valid? A7: Our quotation valid for 1 months. Q8. Can you accept OEM brand? A8: Yes, we can accept the OEM brand without extra charge. Q9. How long is your product warranty? A9: 7 days replacement and 12 months repair free of charge for quality problem. Q10. Can you produce according to the samples? A10: Yes, we can produce by your samples or technical drawings
